Graham Slee Gram Amp 2 SE MM Phono Stage


or 6 weekly interest-free payments from $116.50 with Laybuy what's this?

An amazing little RIAA preamp for moving magnet, high output moving coil and moving iron phono cartridges. It’s quite a gem as you’ll find!

The Gram Amp 2 Special Edition RIAA preamp was first launched in 2001 with a number of improvements over the legendary budget Gram Amp 2 “Communicator”. The Special Edition features 50 percent more gain to deliver a higher output which is a closer match to digital sources.

Originally built as an entry-level RIAA preamp for the USA market, It’s earned itself several recommendations with the American Hi-Fi press.

  • Fast-Active preamp and equalisation technology
  • Inherent reduced vinyl click and pop characteristic
  • Rock steady sound stage
  • Truly 3D performance
  • Superior classic ground configuration
  • Can be upgraded by using a PSU1 unipolar power supply instead of the “green” switched mode unit supplied

Input range: 2mV – 10mV rms
Output range (for above inputs): 224mV to 1120mV rms
Gain: 41dB (Av 112) ref 1kHz
Phase margin: 90 degrees
Maximum input level: 41mV (ref: 1 kHz)
Input impedance resistive: 47k Ohms
Input impedance capacitive: 100pF
Output noise: (CCIR Q-Pk 22Hz-22 kHz) -74dB
Equivalent Input Noise (EIN) -115dB
Reproduction characteristic: RIAA within 0.5dB total deviation 20Hz-20kHz
Total Harmonic Distortion plus noise measured at 80Hz, 1kHz, 5.6 kHz and 16 kHz: <0.05% (typically <0.015% at 1 kHz)
Channel balance: 0.1dB
Channel separation: 64dB
Size: 107 x 117 x 50mm approx.
