Bowers & Wilkins CCM684 In-ceiling Speaker


or 6 weekly interest-free payments from $166.50 with Laybuy what's this?

The Bowers & Wilkins CCM684 In-ceiling Speaker are part of  their esteemed line of Performance Series in-ceiling speakers.

Each one pairs an 8″ glass-fiber woofer with a 1″ soft dome tweeter — a potent combination for high-quality sound from above.

Available On backorder

Bowers & Wilkins CCM684 In-ceiling Speaker

The Bowers & Wilkins CCM684 In-ceiling Speaker is a high performance ceiling speaker that’s simplicity itself to install and use. A two-way design, featuring a 200mm (8in) woven glass fibre cone bass/midrange driver and a soft dome tweeter in a neat circular ceiling mount chassis. The tweeter housing pivots for adjustable off-axis treble response and the speaker also features a three-position EQ switch for a better off-axis response. Incorporating QuickDogs™ and a plug-and-play functionality it is quick and easy to install.

Product is Available to Order. Pricing is for each.


  • Ideal for an in-ceiling music system, or as overhead sound effects channels in a Bowers & Wilkins home theatre system
  • 8″ glass-fiber woofer
  • 1″ soft dome tweeter
    • tweeter is aimable to direct high-frequency details towards you
    • three-position EQ switch optimizes off-axis response for different tweeter angles
Your favorite music: heard, but not seen

Your home is as individual as the music you love, and so are your particular requirements. Bowers & Wilkins’ range of Integrated Solutions speakers delivers their world-famous sound quality with a range of options to suit every type of home.

Bespoke installations to suit your home

Bowers & Wilkins understands you want superb sound but don’t want to rearrange your home to enjoy it. So, it has developed an extensive range of in-wall and in-ceiling speakers, delivering high-performance options to suit every space and every home.

Hear music exactly as the artist intended

Their Integrated Solutions speakers are built by the same people, to the same standards, and with the same objectives, as their regular loudspeaker ranges. There’s only one difference: these speakers are nowhere to be seen.


General Information

    • Guarantee Period (Months): 60
    • Output: Stereo Pair
    • Power Type: Passive


    • Home Cinema
    • Stereo Music


    • Visible Colour: White
    • Visible Shape: Circular


    • Cutout Diameter (mm): 250
    • Mounting Depth (mm): 133
    • Overall Depth (mm): 137
    • Overall Diameter (mm): 290

Detailed Specifications

    • Compatible Amplifier (Watts RMS): 25 – 130
    • Frequency range (Hz): 35 – 50000
    • Nominal Impedance (Ω): 8
    • Max Power High (Watts): 130
    • Sensitivity (dB): 88

Driver Information

    • Bass: 1
    • Biggest Driver Size (mm): 200
    • Tweeter: 1
