The SC-6LS MK2 deploys advanced vacuum tubes, coupling capacitor, carbon film resistor and a variety of high-class components. Effectively improved performance and audio quality. Collocated with 9084D MK2, creates an evolutionary home audio system concept.
Cayin SC-6LS MK2 Pre-Amplifier
$5,499.00
Cayin SC-6LS MK2
Available On backorder
Cayin SC-6LS MK2 Pre-Amplifier
$5,499.00
- The new design SC-6LS MK2 deployed advanced vacuum tubes, coupling capacitor, carbon film resistor and a variety of high-class components. Effectively improved performance and audio quality. Collocated with 9084D MK2, creates the evolutionary home audio system concept.
- Constructed linear amplifier circuit with FOUR Electro-Harmonix 12AU7EH Preamp Tubes.
- Advanced rectifying circuit with TWO RCA 22DE4 Rectifiers.
- Deploys Multi-cap Coupling Capacitors & Takman Carbon Film Resistors.
- Designed for 15dB gain.
- Customised EI-Core Power Transformers.
2 V (22 V Max.)
Tubes
4 x 12AU7EH, 2 x 22ED4
Frequency Response
5 Hz ~ 100 kHz (-1 dB)
S/N Ratio
95 dB
THD
0.4% (1 kHz)
Output Impedance
280Ω
Input Sensitivity
350 mV
Input Impedance
100 Kiloohm
Gain
15 dB (1 kHz)
Input Terminals
1, 2, 3, 4
Power Consumption
45 W
Dimensions (W x H x D)
286 x 193 x 328 mm
Weight
12.5 kg
Warranty
2 years ( 3 months for tubes)
