Optoma EH512


or from $2,599.00 today & 5 weekly interest-free payments of $300.00 with Laybuy

In stock

Optoma EH512 large venue projector boasts a high brightness of 5000 lumens, produces 1080p images for sharper, clearer images and presentations.

  • 5000 high lumens of brightness
  • Supports Vertical Lens Shift
  • 1.6X zoom lens enables a larger throw distance range
  • 2D Keystone Correction & 4-Corner Adjustment
  • USB Reader and USB Display
  • Network Display via LAN and WiFi
  • Split Screen Function

Key Features

DLP® technology

DLP® technology from Texas Instruments® is widely recognized and acclaimed for its unmatched reliability and long lasting image performance. When combined with high brightness and native contrast ratios, it becomes the obvious choice for demanding applications. Independent testing has proven DLP® to be the most reliable of projector technologies. Whilst other technologies may show image quality decline after only a few thousand hours, DLP® technology can remain unchanged over hundreds of thousands of hours. Images remain accurate, and colors suffer virtually no degradation over time.

Stunning Image Quality

Full HD 1080p resolution delivers impeccable image quality associated with the best digital cinema performance around the world. Digital HDMI or DVI signals create a true digital projection system that produces a spectacular High Definition display. This unprecedented combination ensures natural, life-like images with crystal clarity.

Vertical Lens Shift

Vertical lens shift gives you the ability to move the projected image up or down, while keeping the projector stationary. This makes it easier to position the projector in large venue or meeting room, and enables a wider range of screen size options.

1.6X Zoom Lens

A 1.6X zoom lens enables a larger throw distance range, easily creating a stunning 120-inch image from just 3.7-6.0 meters away.

4 Corner Adjustment

By individually adjusting each corner of the image, our 4-Corner Adjustment eliminates any crooked or distorted images in off-angle or restricted space installations for that perfect picture.

2D Keystone Correction

Digital horizontal & vertical keystone lets you adjust the form of an image to get a proper rectangular shape on both sides. It is flexible for limited space configurations such as when the projector is placed indirect to the screen or at an off-angle.

Auto Vertical Keystone

Adjust the vertical image angle to project a perfect square image automatically. Auto keystone correction makes it easy to set the screen configurations from a variety of locations.

USB Reader

Photo and document viewer

Users do not always require a PC or mobile device to display content. With the built-in USB reader, simply by plugging in a USB storage device, users can directly view photos and documents including PowerPoint, Word, Excel and PDF file formats.

USB Display (Android, IOS only)

Screen mirroring by USB cable

Mirror your iOS or Android screen by connecting the device to the projector with your USB charging cable. Conveniently and easily share your content to the big screen.

LAN Display

Screen mirroring via the LAN connection

Via LAN connection, you can mirror your PC or laptop display to the big screen. Specially designed for business and education environments, up to 4 computers can project the content simultaneously. Suitable for co-operative team based work, LAN Display will greatly improve the efficiency of the meeting.

*HDCast Pro app is required.

Versatile System Integration Control Protocols

Crestron RoomView, Extron’s IP Link and PJ-Link protocols are fully supported, allowing nearly all aspects of the EH512  to be controlled across a network, keeping you in control.

Wireless display

Wireless projection with optional Wi-Fi dongle

With an optional WiFi dongle and using the free mobile APP, you can wirelessly connect to your laptop, tablet or mobile device and project your content to the big screen. Up to 4 devices can be connected to the projector simultaneously. With WiFi display, you can eliminate cable clutter and increase connection versatility.

Split Screen

Through our free app, the HDCast Pro, projecting up to 4 images simultaneously from different images sources can greatly improve the efficiency of the meeting.

Sketch Function

Through our free app, the HDCast Pro, marking your shared content at your fingertips for effective interaction.

MHL Display

Connect your mobile device directly to the projector by using a single MHL cable. Play stream videos and share photos on the big screen.

Display Technology DLP
Native Resolution 1080p 1920 x 1080
Brightness 5000 ANSI Lumens
Contrast 15,000:1
Lamp Life 3000 / 5000 / 6000 / 7000 (Bright/Eco/Dynamic/ECO+ mode)
Zoom Type 1.6x Manual
Speaker (Watts) 10W x 2
Keystone Correction ±20° Vertical, +20° Horizontal
Weight (Kg) 4.6
Dimensions (W x D x H) (mm) 369 x 295 x 123
