Sumiko Palo Santos Presentation MC Cartridge

$9,699.00

A ‘reference’ cartridge strives to transcribe that extra bit of musical information that makes your music come alive. Subtleties like the snap & thump of the kick, the attack & rustle of the snare, fingers on the fretboard & vocal verisimilitude are just a few of the attributes a high-end MC is tasked with extracting and reproducing. Beyond just reproducing them, it must be a highly refined ‘Presentation’ across the frequency spectrum with an intimate awareness for the nuance that elevates performance beyond what can be expected from more affordable MCs.

Available On backorder

Sumiko Palo Santos Presentation MC Cartridge
Sumiko Palo Santos Presentation MC Cartridge
$9,699.00

Contact Us
First
Last

A high-end wonder that performs at the level of more luxuriously priced moving coil designs, Sumiko’s Reference Palo Santos Presentation is primed to deliver this magic to your audiophile-caliber system. We’ve selected the gorgeous, hand-crafted Brazilian Rosewood housing for its resonant properties — the homogeny & warmth that it lends to a sophisticated, crystal-clear sonic picture that’s teeming with micro-detail. Featuring an ultra-rigid long-grain boron cantilever and line-contact Microridge stylus, tracking is superb and the groove is traced with the utmost finesse. Anchored to an uncompromising machined aluminum cradle and enclosed by a milled Teflon back plate, maximum rigidity and resonance control around the generator are achieved. This allows the voice of the cartridge to sing unimpeded by unwanted coloration and interfering resonance, precipitating to unrivaled honesty in playback.

On the bottom end, bass is buttery and inviting, ever-present and non-dominating. Lush & textural, it emerges from a silent backdrop and remains impeccably defined. Mids are free of clutter & confusion. Instruments and their nuances are vividly tangible while maintaining their natural warmth. Highs are enchantingly airy and wonderfully extended with a sparkle that promises to mesmerize. You can feel the emotion in dynamic shifts, and the musical material resolves effortlessly with charming decay back into the backdrop. Multidimensional yet whole and blossoming with previously unrealized sonic imagery, the result is an uncanny portrayal of your of your most cherished recordings.

Cartridge Fitting Service $30.00

Hand-Crafted in Japan

From Oyster to Reference, each Sumiko phono cartridge is crafted by hand in Yokohama, Japan — near the waters where our namesake Oysters dwell. We’ve selected by ear the finest materials that combine to deliver performance that has enlightened generations of listeners. Each design is thoroughly auditioned until perfected. Production is then executed by world-class cartridge makers with a collective eye for precision & quality. The result is a full horizon of cartridges eager to introduce themselves to your analog system — we firmly believe there’s a perfect cartridge for you here.

Mass & Dimension
8.3g, 18 x 17.2 x 30.5mm (WxHxD)

Stylus
Solid Ultra Low-Mass 75µm x 2.5µm Microridge

Cantilever
⌀0.28mm Boron Shaft

Coils
High-Purity Copper

Internal Impedance
12Ω

Load Impedance
100 – 1kΩ

Frequency Response
10Hz – 50kHz

Output Voltage
0.5mV

Channel Separation
30dB @ 1kHz

Channel Balance
<0.5dB @ 1kHz

Compliance
8×10-6cm/dyn @ 100Hz

Capacitance
100pF – 200pF

Vertical Tracking Angle
20°

Tracking Force Range
1.8g – 2.2g

Recommended Tracking Force
2.0g

Replacement Stylus Unit
Re-Tip Exchange (See Dealer)
