TEAC TN-175 Analog Turntable

Original price was: $399.00.Current price is: $299.00.

Available in White only.

2-speed full-automatic analog turntable with auto-start for LP/EP and auto-return mechanism.

TN-175 is a 2-speed full-automatic belt-drive turntable supporting 33/45 rpm. It comes with built-in phono equalizing amplifier, phono and line outputs and a VM(MM) type cartridge AT3600L by audio-technica.

Out of stock

Notify me when the item is back in stock.



  • Full-automatic belt-drive turntable
  • Auto-start for LP and EP, and auto-return mechanism
  • Static-balance straight tonearm
  • High-Quality MDF construction for improved resonance reduction
  • Vibration absorbing rubber bumper feet
  • Detachable acrylic dust cover
  • Built-in MM-type phono preamplifier
  • High-quality VM-type cartridge AT3600L by audio-technica pre-installed (Equivalent to MM-type)
  • PHONO and LINE outputs (Switchable)
  • 2-speed (33-⅓, 45 rpm)
  • Sleek design in black or white finish
Turntable section
Drive System Belt Drive
Motor DC Motor
Speed 33-⅓ rpm, 45 rpm
Wow and Flutter 0.2% or less
Signal-to-Noise Ratio 67dB or higher (A-weighted, 20kHz LPF)
Platter Molded resin
Diameter of Platter 290mm
Tonearm section
Type Static Balance, Straight
Effective Arm Length 207.9mm
Tracking Force 3.5g
Cartridge section
Type VM (equivalent to MM)
Output Voltage 3.5mV (1kHz, 5cm/s)
Tracking Force 3.5g ±0.5g
Cartridge Weight 5.0g ±0.3g
Head-shell Weight 10g (including Screws, Nuts and Wires)
Phono Equalizer Amplifier
Type of Amplifier MM type (On/Thru switchable)
Analog Output
Connector RCA Pin jack (Gold-plated) × 1 pair
Output Voltage Phono/Line switchable
Phono Output 2.5mV
Line Output 150mV
Power AC 100-240V, 50/60Hz
Power Consumption 6.0W (less than 0.2W at Standby)
Overall Dimensions
16.5″ × 4.1″ × 14.0″
420 × 105 × 355 mm
Weight Approx. 7-¾ lbs. / 3.5 kg
Accessories Rubber Mat, EP Adapter, VM-type Cartridge (AT3600L, Pre-installed), Platter, Dust Cover, Hinge × 2, RCA Audio Cable, AC Adapter (GPE053A-120050-Z), Owner’s Manual (including Warranty Card for US/Canada)
