Audio-Technica AT-VM95SP/H

$279.00

In stock

The AT-VM95SP/H combo kit includes the AT-VM95SP dual moving magnet cartridge premounted on the AT-HS6BK headshell.

78 Cartridge

  • VM dual magnet cartridge with 3.0 mil conical stylus
  • Aluminum cantilever
  • Specially wound coils increase output voltage
  • Durable low-resonance polymer housing
  • Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts or washers required
  • Compatible with any AT-VMN95 replacement stylus
  • Universal ½”-mount headshell for 4-pin turntable cartridges
  • Frequency Response 20-20,000 Hz
  • Channel Separation NA
  • Vertical Tracking Angle 23°
  • Vertical Tracking Force 4.5-5.5 g (5.0 g standard)
  • Stylus Construction Bonded round shank
  • Recommended Load Impedance 47,000 ohms
  • Coil Impedance 3.3 k ohms (1 kHz)
  • DC Resistance 485 ohms
  • Coil Inductance 550 mH (1 kHz)
  • Recommended load capacitance 100 to 200 pF
  • Output 2.7 mV (1 kHz, 5 cm/sec.)
  • Channel Balance 1.5 dB (1 kHz)
  • Stylus Shape 3.0 mil conical
  • Cantilever Aluminum pipe
  • Mount Half-inch
  • Weight Cartridge 6.1 g (0.22 oz); Cartridge & Headshell 15.5 g (0.55 oz)
  • Dimensions Cartridge 17.2 mm (0.68″) H × 18.9 mm (0.74″) W × 28.3 mm (1.20″) D; Cartridge & Headshell 21.2 mm (0.83″) H × 21.4 mm (0.84″) W × 62.4 mm (2.46″) D
  • Replacement Stylus AT-VMN95SP
  • Accessories Included Two 11 mm installation screws, two 8 mm installation screws, two washers
